| Processor | Intel® Celeron® J6412 Processor (up to 2.60GHz) |
| Graphics | Intel® UHD Graphics for 10th Gen Intel® Processors |
| BIOS | AMI BIOS, 128M-bit SPI Flash ROM |
| Chipset | Nuvoton NCT6126D |
| Memory | Single 260-pin DDR4 SO-DIMM Socket,4GB DDR4 by default,Supports Up to 32GB DDR4 3200MHs (non ECC Supported) |
| Storage | 256GB M.2 SATA SSD(Upgradable to 1TB}, 1 x SATA3.0 |
| Video Output | HDMI 2.0 Max resolution 4096x2160@60Hz
DP 1.4a Max resolution 4096x2160@60Hz
Dual Display |
| I/O Ports | 3 x USB 3.2 GEN1 Type A
1 x USB 2.0 Type A
4 x RS-232 I 422 I 485
2 x RJ-45 |
| Expansion Slots | 1 x M.2(Key-B,3042,PCIe x1 +USB3.0), 1 x M.2(Key-M,M.2 SATA 2242/2280) |
| Power Supply | DCIN +12V-24V ±5% |
| LAN | 2 x 1 0M/100M/1000M/2.5G Ethernet |
| Dimension | 175 x 106 x 56.5mm |
| Audio Output | Mic-In, Line-Out, 2-in-1 3.5mm audio jack |
| Audio | ALC897-VA2-CG |
| OS and Storage Manager | Windows 11 Pro |
| Environment | Operating temperature: -10°C~60°C
Storage temperature: -40°C ~ 85°C (-40° F ~ 185° F) |
